Dolly for Galaxy Sander

Heavy-duty travel dolly engineered for professional floor sanders. Features 5-inch diameter non-marking rubber wheels designed to glide smoothly across uneven surfaces without marring floors. Spring pin attachment ensures secure mounting with tool-free removal, while the adjustable bolt accommodates various casting sizes for a custom fit. Installs and detaches in seconds—no machine modifications required. Compatible with Galaxy 2000, Omega, and Sirios floor sanders. Keep your equipment mobile and protected.

• Product Code: GALDOLLY

GALDOLLY Installation instructions:
1. Turn machine upside down.
2. Install Dolly, making sure the ear for the belt cover goes in
notch on dolly (see picture #1).Be sure spring pin fully
latches.
3. Using 2) ½” wrenches, loosen bolt & nut in back corner.
4. Push dolly forward & toward belt guard as far as it will go.
5. Push bolt into corner (back & away from belt guard- see
picture #2) & tighten.
6. Make sure dolly will not come off without being unlatched
by pulling outward on front axle & left side. If dolly can be
moved enough to unlatch tabs from sides of machine,
readjust.
7. Remove & reinstall dolly to be sure it fits properly.
8. Now the dolly is ready to use. It can be installed by tipping
the machine forward, rolling the dolly underneath, and either
pulling the machine back on the dolly, or lifting the dolly up
to latch it on the machine.
Note: due to the variation in machine castings, the dolly may
need to be adjusted differently for each machine.
